A 400cc water cooled four stroke engine with EFI and a part time 4WD system drives this gasoline ATV through a shaft CVT to 75km/h with about 200km range. A front differential lock, winch, four wheel disc brakes and 25 inch alloy tires pull through snow and mud, carrying 280kg. This exporter supplies ODM builds and bulk purchase terms.
You can click on the shopping cart to learn more about details, availability, and prices.
| ① Dimension | 2080x1100x1160mm |
| ② Seat height | 830mm |
| ③ Wheelbase | 1300mm |
| ④ Ground clearance | 190mm |
| Engine | 400CC Single-cylinder, water-cooled, four-stroke |
| Bore x stroke | 75x65mm |
| Compression ratio | 11:01 |
| Max power | 17KW/6800rpm |
| Max torque | 28N.m/5500rpm |
| Gear position | L-H-N-R |
| Fuel capacity | 12L |
| Ignition | EFI |
| Startup type | Electric start |
| Suspension | Front: Double A-arm Rear: Independent suspension |
| Braking | Front and rear four-wheel disc brakes |
| Shock absorption | Front and rear hydraulic shock absorption |
| Driving mode | Part-time 4WD |
| Transmission | Shaft CVT |
| Tyre | front: 25×8-12 alloy rear: 25×10-12 alloy |
| Gradeability | < 45° |
| Range | About 200km |
| Max. speed | 75km/h |
| Max load capacity | 280kgs |
| Specific configuration | bashan 350 ( customer normally mark 400cc) EFI , winch, mudy style. LCD meter, 4WD adjustable, front differential lock, heat grip |
| Weight | 370kgs |
| Carton size | 2004x1134x840mm |
| Color | Black/Orange |
| QTY | 36pcs/40HQ |
Wuyi Mole Motion Apparatus Co.,LTD.(brand: ATVIMX), established in 2016, is a professional off-road vehicle manufacturer integrating R&D, intelligent manufacturing, sales, and global export.Our company is equipped with automated robotic production equipment and has built standardized intelligent production lines coverin......
We offer ATVs, dirt bikes, go-karts and full accessories, covering kids & adult leisure, racing and amusement scenarios.
We provide OEM private labeling and ODM full R&D customization for off-road vehicles. Add your logo to our mature ATV platforms or build exclusive models from scratch. Our team offers full-chain one-stop solutions for your market.
Our intelligent robotic production lines cover stamping, welding, assembly and full safety testing to guarantee consistent quality and on-time delivery.
